उत्पत्ति के प्लेस:
चीन
ब्रांड नाम:
WENYOU
प्रमाणन:
CE/RoHS/UL/REACH/ISO
मॉडल संख्या:
LE-8516 और LH-8516
वीडियो
| Attribute | Value |
|---|---|
| Flexibility | High |
| Solvent Resistance | High |
| Usage | Electric insulation |
| Cure Temperature | 130-140℃ |
| Moisture Resistance | High |
| Heat Resistance | High |
Epoxy Resin LE-8516 and Hardener LH-8516 form a modified, weather-resistant anhydride-cured system designed for demanding industrial applications. With a 1:1 mixing ratio by weight, this combination delivers exceptional mechanical strength, thermal stability, and electrical insulation—ideal for coatings, encapsulation, and structural composites.
| Epoxy Resin LE-8516 | Hardener LH-8516 |
|---|---|
| Appearance: Transparent, pale yellow, viscous liquid | Appearance: Transparent, pale yellow liquid |
| Epoxy Value: 4.5-5.0 Eq/kg | Viscosity at 25°C: 200-500 mPa.s |
| Viscosity at 25°C: 500-1000 mPa.s | Density at 25°C: 1.16-1.20 g/cm³ |
| Density at 25°C: 1.17-1.24 g/cm³ | Flash Point: ~135°C |
| Flash Point: ~140°C | Vapor Pressure at 25°C: <0.01 Pa |
| Vapor Pressure at 25°C: ~0.5 Pa |
A: LH-8516's lower viscosity (200-500 mPa.s) improves filler (e.g., silica flour) dispersion and reduces air entrapment during mixing.
A: Exceeding 350 pbw may compromise mechanical properties. Conduct trials for your specific application.
A: Yes. Post-cure (130-140°C * 6-10 hrs) ensures full crosslinking and optimal thermal/electrical performance.
A: Anhydride curing offers lower exotherm, reduced shrinkage, and better UV resistance vs. amines.
A: Use PPE (gloves, goggles); ensure ventilation (vapor pressure: resin 0.5 Pa, hardener <0.01 Pa)
